Tuesday, November 7, 2017

Resource misallocation

Recently read about the new sky scraper being built in Chicago. It will be the third highest structure there, and will be done in a couple of years. And here I thought Chicago was in deep financial trouble, had plenty of available office space, and generally was over the ego driven need to build these phallic monuments. The last big one was topped out in 2009 (A trump tower no less!).

Turns out this one is for very high end condos and a hotel. A Chinese company is making it happen. I guess there are still a lot of millionaires in the Chicago area that would go for a nice view of Lake Michigan. (Or millionaires looking to move some assets out of China and invest in a "stable" location).
https://www.vistatowerchicago.com

And there are also a lot (54!) of other, shorter buildings being built, but still very tall and elaborate.
https://chicago.curbed.com/maps/chicago-tower-highrise-construction-map

Skyscrapers are very complex structures, use huge amounts of materials, and are very dependent on a fully functioning economy, stable utility costs, and paying tenants. There have been a few articles in the past pointing out how the ultra high sky scraper craze has taken off and given the host countries some sort of ego boost.

China alone built 84 skyscrapers in 2016!!
https://qz.com/883681/shenzhen-built-more-skyscrapers-in-2016-than-the-us-and-australia/

And it appears that here is a weird correlation between skyscraper frenzy and imminent economic collapse:
https://www.theguardian.com/business/2012/jan/11/skyscrapers-china-india-recession
if this correlation holds, then rough times are ahead.

Regardless if economic collapse follows, skyscrapers are, I would argue, a vast resource misallocation. While they improve city density, density is not an automatic good thing. A downtown that is too vertical can be sterile and uninviting, and large buildings can mean lots more long distance commuters.  Instead of walkable cities or neighborhoods, we get harried train riders.

I have no expertise in city planning, but from a purely resilience viewpoint, skyscrapers seem vulnerable and brittle in response to changed conditions. Makes you wonder why mayors, city councils, zoning and permitting departments encourage them. A single story building, or even one that is walkable can be designed to be habitable without power, but not skyscrapers. They do not function without large amounts of electricity.

It's one thing to tear down a three story building or a big box store that has become obsolete, but tearing down a scraper that no one wants would be a formidable task, and a real waste of resources.

Where should a city, or a country be investing in infrastructure, housing stock, utilities, and so on? A look in to the future is needed, and a frank assessment of the available funds to do any chosen plans.

With the remaining "cheap" energy and resources left to us, I would argue that we as a minimum stop building infrastructure that is highly grid dependent and can't be repurposed. The wider question is, what should we be building, or not building?

Here are a few principles I will throw out, which COULD be used as a checklist to wisely build, but won't be. They assume vastly less energy and materials available in the coming decades to continue building like we have up to now.

The majority of transportation infrastructure spending should be shifted to rail and mass transit, instead of adding new roads. NO NEW ROADS.

Any existing transportation infrastructure should be repaired and modified so that it either is very cheap to maintain (gravel roads) or built like the Romans, with a design life in centuries. Obviously, only a few main arteries would justify the later approach. There are already a lot of  rural local government units choosing to transition paved roads to gravel because of tight budgets. This trend will increase.

Overall, transportation infrastructure will need to transition ( over ~50 years?)  to facilitate local transport, with minimal regional or national traffic assumed.

Any new housing infrastructure should be built with nears zero energy needs, like the passive haus movement out of Germany.  https://en.wikipedia.org/wiki/Passive_house

All existing housing should be evaluated to be either recycled at the end of its useful life, or upgraded to as near to passive house standards as possible.

All new structures should be designed to beyond LEED certification, such that they have very low life cycle environmental impact. This can be done either through completely renewable materials and simple construction, or very long life span design, measured in centuries. and designed to be easily maintained.

Yeah, these pie in the sky goals are not politically or culturally viable here in the states, but the funny thing is, as we continue to transition to a low energy society, ( fossil EROEI continues to decline) at some point we will be stuck with the built infrastructure we have.


Here is an example of resource allocation I have chosen. This apple grinder and press will last for decades if stored and taken care of properly, and needs no electricity, no further fossil fuels than were used to create it, and just needs friendly neighbors to come help during harvest time.








Sunday, October 22, 2017

nothing goes to waste: black walnut edition

I did a post back in Feb 2016 on black walnuts, but have a couple new observations to share. Last year we had zero nuts because of bad timing on a late hard frost in our area.

This fall is a very heavy nut crop in the woods around here. Some years there are very few, so one had best gather while the gathering is good. We don't have commercial nut orchards, but plenty of "wild" black walnut and shagbark hickory trees to forage from.

I've been gathering, processing, and storing, noting at the same time that most nuts go unharvested. It was this way in the suburbs, where they are often considered a nuisance, but even here in the country there isn't much competition when nut gathering.

The black walnut has a thick, green husk around it while growing, and when nuts first drop from trees, the husk is often still firm and hard to remove. Most people who are aware of black walnuts at all say to dump them in the driveway and run over them with the car, but that seems like a real pain to me. After a while on the ground, the husk starts darkening, even all the way to black, and gets soft and mushy. I found that by just waiting till this happens, the husk comes off very easily, if messily.

What one finds, though, is that the black slimy mess is almost always crawling with some sort of maggots. Looks kind of gross the first time you see them.

Turns out that there is a single fly species, the walnut husk fly, that competes its life cycle by eating on the slowly rotting husk. Now, I find this to be a real convenient collaboration, as the maggots eat and soften the husk, without damaging the nut, and makes my husking operation much easier.

This husk, which the tree expended energy to produce, is now feeding another species, which as far as I can tell, affords the walnut tree no reciprocal benefit. No waste here, nature has found an energy resource and filled the niche. I think the husk, which contains a fair bit of juglone, may act as insect protection, which the husk fly has evolved to resist.

And in yet another commentary on the perverse industrial ag approach to things, nut producers in the west of the U.S. consider this a big problem, to be dealt with by using pesticides to kill the flies. Why? They are concerned about the cosmetic appearance of the shells, which will be darkened by the rotting husks. Some sources I read voiced concern that the dark juice will actually soak in and stain the nut meats themselves, but I have never seen this.

Unshelled walnuts store very well, the nuts themselves are a good source of fats and calories, and are free for the harvesting, so those of you where they grow, what's keeping you from gathering some yourselves?






Tuesday, September 12, 2017

optimal foraging theory

I was reading a bit about optimal foraging theory in Wikipedia, https://en.wikipedia.org/wiki/Optimal_foraging_theory

Basically, the theory describes how organisms utilize strategies to optimize their energy return on the effort to find food. The same concept as EROEI, which those who follow peak oil and civilizational prospects think about a lot.

It's really just common sense that those individuals that have behavior patterns that get the best bang for the buck will reproduce better, and thus there will be a genetic drive toward pattens that optimize energy used in gathering more energy.

But it gets more complicated when you consider the competition between other species in the same or similar ecological niches, and the fact that there is more than one way to get good energy return. One might opt for a high energy effort, high energy return approach, or a low energy expenditure, low return approach. Some strategies are good for short term advantage, some are conservative, but win over the long haul. And there are many other strategies that might end up playing out as a group or a set area, as long as the net return is optimized.

So it occurred to me that really, that's all us humans are doing, following a well trod path as any successful species would. The studies that have been done all look at bugs, or birds, or fish, but wouldn't it be interesting for the theorists to look in the mirror. Physics and biochemistry underlay it all. In our daily lives, in our societal organization and in our exploitation of resources, we are really doing no more than a gazelle or a mole would do.

But- We have the special ability to pass on behaviors to others through our complex communication , both to contemporaries and future humans, so improved species wide energy return improves in hours, days or years, instead of countless generations. To top things off, once we began leveraging our tool making ability to harness fossil sun energy, well, we blew the doors off any predictions on how our niche in the ecosystem might have played out.

So what does this portend for our future? How will this inherent property of humans and all organisms affect how the end of fossil fuels plays out in the coming century? Is our species locked in to hard wired behavior patterns, where the "survival of the fittest" approach wins out, or will a different pattern, like symbiosis, or cooperative collaboration win out? Will we play the long game, and start repairing the frayed web of life, maximizing the local carrying capacity for us and all species, or will we play the short game, and join the yeast in the petri dish as another example of fast and short population growth and decline?

The world is a big place, and nature has many parallel experiments going on at all times, so we might see both, and many variations of each. I plant trees.

For a lighter end to this entry, here are some photos of a recent effort to harvest energy, utilizing tools and learned behavior. We and our neighbors took advantage of a good apple year, as both domestic trees and feral trees with passable taste are bearing heavy this year. Since we do very little in annual management of the trees, our return should be pretty high.


The new apple grinder and press, ready for action.

From our best tree- No chemicals, no worms, no apple scab or fire blight- it was a good year, and unreal production. We had about 15 buckets full from this one tree. ( And countless falls that the chickens took care of) The later ripening varieties will get their turn in a month or so.
I'll do another post soon, showing the press in action, as well as bottling the cider I have fermenting now.

Sunday, July 30, 2017

pushing electrons

The photovoltaic phenomenon is described as photons knocking electrons out of their valence orbital and creating a net charge in a semiconductor. There are holes, and dopants, and depletion zones, but I don't pretend to understand the nitty gritty physics of it. Sure is a handy property of semiconductors.

Lots of physics research, material science, high tech fabrication techniques, and government encouragement went in to the solar panels we installed this summer.

The key here, is that once the PV cells and panels are built, they keep generating electricity from sunlight for a really long time. Big payment up front, then "free" power for years.

I know that the federal tax credit for installing residential renewable energy is phasing out over the next few years, so decided to make our move now.

We are now producing our sun driven electricity, to the tune of 4.9 kW nameplate capacity. So far, our peak output was 4.4 kW, but don't know what has to align to get the full capacity. For the year, this is prime solar weather, as the winter and spring are more cloudy.

We decided on ground mount, as we have plenty of unobstructed southern facing land, and I'd just as soon not mess with the roof unless that was a much better option. I also had initially planned to design and build the rack myself. ( maybe another blog entry on how that went down).


Here I am, driving a Bobcat skid steer for the first time, with the 24" (600mm ) dia. auger for drilling the holes for the concrete piers. I am still a terrible operator, but did not kill the guys who came to help. It helped that they were both nimble and quick on their feet.

Here are the rack columns in the concrete forms, braced and ready for the  pour. The holes are six feet deep. This rack is not going anywhere.


The design for the rack required huge piers, totaling 2.5 cubic yards ( 1.9 cubic meters) of concrete between the three of them. I looked at renting a mixer and doing it by hand, but the cost was not that much higher to order the truck, and WAY less labor.

Had to dig the trench from the array to the inverter in the barn by hand. No fun in the heavy clay mixed with large rocks. Code requires top of conduit to be 18" (450mm) below ground.


Here is the finished array, soaking up the sunshine. The panels themselves are super easy to install ( as long as the rack was put up level, straight, and plumb!), and the cabling is all premade with simple plug ends. This particular design is a single string, 350VDC output with optimizers at each panel.

Pulling the home runs, terminating, tying in to the power panel were done by an electrician. I might have been able to figure it out, but he was way quicker than I would have been, and one of the grants we are going for requires a master electrician to sign off on it.

If we decide to go off grid, we will need to spend for the batteries, as well as the charge controller and a different inverter. We are a ways off from that, as we would need to reduce our load, and really do some self reflection on how much lifestyle change we would be comfortable with.



Monday, July 3, 2017

There are more things in Heaven and Earth, Horatio..........

https://en.wikipedia.org/wiki/Tacit_knowledge

This concept came to my attention the other day, and got me to thinking how it applies to our present society.

Tacit knowledge is knowledge that is difficult to transfer through written or spoken methods. Some examples are throwing a ball, playing an instrument, recognizing someone's face, or kneading dough. Many, but not all examples of tacit knowledge involve physical activities or modes of expression.

Since I have recently been trying to learn to identify edible plants, and to identify trees by their bark, I  find that words just can't cut it sometimes, and when it comes to eating a foraged plant, I darn sure want to walk the woods a few times with a pro until I finally see the essential differentiators of the plant, even if I find it hard to put in to words.

In the past, tradesmen, craftsmen, artisans took on apprentices, and over time, their knowledge was transferred, but was very difficult to codify.

In our ( at least in modern western countries) economies and social networks, things have become very written and oral and much less face to face or involve mind body coordination. Petabytes of information scurry around the world, as humans communicate and conduct commerce, but what is this doing, what has it done to our psychological makeup?

How does it affect our ability to empathize, to have a grounded feel for what might be true? The subtleties that abound in perfecting any new skill help one realize that sometimes the truth is too hard to capture on paper, and that maybe there are more things in heaven and earth than are dreamt of in our philosophies?

Are our brains being stretched to the limits by so much of one kind of learning , but much less of another? Why are those skills that involve kinesthetic intelligence or hands on craft abilities less prestigious or remunerated in our society?

The future I see is one where tacit knowledge transfer will regain prominence and will supplant the current mode of explicit knowledge transfer. In fact, further, the types of skills that are considered tacit knowledge will become much more important as muscle power and local economies slowly replace our fossil fuel driven economy.

Our education system has for a long time been losing its way, and not preparing our young for the real world they will have to navigate and earn a living in. Many are sensing that now, but how will the transition happen?




Thursday, April 20, 2017

descent engineering

My career before I retired was as an engineer for a large design/construction company. I helped build the energy industry infrastructure all over the world. If I had it to do over, I would not have contributed to the extraction of nonrenewable resources, but that's what happened, and time to move on.

Engineering has a very large number of sub disciplines, but the general categories are usually listed as civil, mechanical, electrical, and chemical. A few others that sometimes are considered top level categories are cost, biomedical, and systems engineering. If someone thinks another should be added, I'd not quibble.

Engineering is still a very important human activity, but as with all other human endeavors, needs to be marshaled wisely, instead of being yoked to the short term profit driven economy we now "enjoy". Even from the long term view, our ability to take raw materials, and through methodical steps, fashion all manner of artifacts is amazing. During this fossil fuel enabled bonanza, we have been able to create millions of items, devices, and structures to make our lives easier.

As we face the end of cheap energy, the end of fossil fuels, and the general decline in easily extracted raw materials, we are on the cusp of a new phase in human history, and a large challenge in fashioning the artifacts that enables us to live in reasonable comfort.

So how will the engineering professions have to change? What do you do when the dozens of manufacturers ready to supply any component you need for your design are no longer there? What do you do when the advanced materials and techniques are no longer economic or even available?

I've begun a list of the new parameters that future engineers will need to consider and take in to account for their designs. This list is more on the technical side of things, and assumes that the ethical, sociological, environmental and systems thinking parameters are already a given. ( They are not yet, but that is a whole other post)

For that matter, will we even have "engineering" in the far future, meaning design using stress analysis, calculus, other forms of higher math, or will our built environment and artifacts be done at the level of craftsmen and passed down experience? I think for a generation or two at least, we'll have engineering, but it will have to change with the newly prominent parameters.

What are the new design parameters? How far down the road are they useful and relevant? How quickly will we be needing these new approaches?

In no particular order, here are some.

corrosion- Right now, nearly all ferrous things are just assumed to rust away as part of the natural way of things. Everything from ocean going ships to fencing to pipelines to cars are given some level of corrosion protection, but not enough to extend their lives beyond years or decades. Certainly not centuries or indefinitely. As iron ores and mining of same reach lower concentration levels, the continual input of new steel will end. We will be left with what we've refined, and must marshal it carefully. Any design will need to minimize the steel used, and make it very protected from rusting away. It would be a damn shame if we slid back to the stone age a couple centuries from now simply because we frittered away our iron.

longevity- Current economics dictate that many items are made to last about a day longer than the warranty. There will need to be a reevaluation on which items can truly be thrown away, made from renewable, quickly fashioned materials, versus items that have a lot of embedded energy, and should be made to last a very long time. There are old farm tractors made decades ago, that are still sound and operational, as they were built to last, and just need periodic maintenance and replacement of small components. Newer tractors have electronics, computers, and have had the weight trimmed to minimize cost, at the loss of longevity. They won't last as long without ongoing high tech support.

design for disassembly, maintenance, repair- this goes hand in hand with the longevity point. It also adds the issue that things should be repairable by the user, and not some tech center that will replace much more than necessary, just to do it quickly. The current approach makes sense when  labor is more expensive than replacement parts, but that will not be the case in the future. This approach to design may well mean first cost is greater, but life cycle cost is much less. In the future we are entering, life cycle costs will predominate, not first cost.

design for renewable inputs only-  where possible, some things should be designed from natural materials. This will limit the possible designs, but function will once again govern rather than form. Folks like Calatrava or Gehry will not be getting commissions. One can look at the amazing cathedrals and stadiums that were built hundreds or thousands of years ago to see that there is still much that can be done with stone and wood.


design for technology suites that won't domino- While it is hard to predict which ones with certainty, some technologies and fabrication techniques will be more likely to become impossible or vastly more expensive. Artifacts in the future should be designed so that they are not prone to single point failure in the supply chain. If semiconductor chip fab ends, then anything using them, even if for a simple sensor, might fail if this one single component is critical for function, so technology selection needs to consider only robust and simple components.

design for simple fabrication techniques- The extremely advanced fabrication techniques we have now are dependent on being part of a fully functioning industrial economy, so it's not just materials getting scarce, fab capabilities will likely degrade as well.

design for intermittent or batch production-  Many parts of our industrial ecology are designed to work 24/7 to make full advantage of the capital investment, and because many processes do not lend themselves to lots of stops and starts. Oil refineries and power plants run for months on end, only stopping for preventative maintenance. Factories, food processing, transportation, heck, everything in our society stops and starts whenever it chooses, because electricity and fuels are ready 24/7. If one starts relying on solar power for heat and or power, then one is forced in to the daily batch cycle, or providing very expensive storage and the associated additional conversion losses. Whatever industry we may have in the future will need to scale to the available solar time frame and energy density.

design for easy bio/tech split- ( McDonough and Braungart)- in their book "Cradle to Cradle", they point out how much of our environment pollution problems are because we mix the technical and biological ecosystems, causing it to be very difficult to recycle or compost. Design needs to keep these two material streams easily separated after an artifact has reached the end of its useful life. Europe is much further along in this area than the U.S. In essence, this concept takes recycling to its full closed loop conclusion.

I will continue to add more of these as they occur to me, but this is already a seismic change in what engineers normally have to consider in designing things.

Thursday, February 16, 2017

chicken predators

We are going in to the start of our third year raising chickens. We'll be ordering some meat bird chicks for starting in May, but figure our laying hens are still producing enough we will go another year with them.

 Chickens are plump, tasty morsels, and they can't fly or fight very well. So all manner of predators just love them. I had seen some signs of digging at the foundation a few times this past summer, and refilled the holes, but the hardware cloth I had buried did its job, and entry was denied. Overall, we'd been lucky, with no hawks, coyotes, or raccoons taking any.

Then...........this February, we had our first predator get in to the coop. Turns out weasels are really small, and after reading up on them a bit, I realize now that I could have avoided this, so had to start working to rectify things.

Here is what happened: First- the uneaten feed in the feeding troughs was attracting mice and rats, who helped clean things up overnight while the chicken slept in the roost.

Second, they dug some tunnels from under the concrete slab section of the barn, providing access from a direction that had not occurred to me.

Third- they are food for weasels, who, by late winter, were getting  a might peckish. I had not minded the mice too  much, and when I saw signs of rats this late fall/winter, decided to start trapping. I got one, but then noticed that there were few new signs, and knew I hadn't scared them off, so wasn't sure what was going on. Maybe they were just getting more sneaky after one fatality?

Well, I now know that the rats attracted a weasel, who mowed through them, but with the rat's thoughtfully provided tunnel system, started taking a chicken every other night or so.
(Weasels are actually a good thing to have on a farm, as they eat mice, voles, other critters who want their share of my garden. Just gotta keep them out of your coop!)

The first chicken had the classic weasel pattern, with the head nearly decapitated, but no the damage to the rest of the chicken ( what a waste!). I mixed up some cement, shoved it up under the slab where the rat holes emerged, and looked around for smaller holes than I had originally thought I would need to worry about. A couple days later, another two hens got it. I found a couple more holes and plugged them. Before it was all over, seven hens had been killed.

Finally, no more hens were being taken, so I figured I had sealed all the holes.

Then this happened

This beautiful, maybe even cute ( but blood thirsty) fellow went in to the rat zapper I had left on in another area of the barn, and got zapped. I had rather he hadn't gotten killed, and actually hope another one takes over his territory, to keep the rats away, just so long as he doesn't get in my coop.

You can see from his size that they definitely punch above their weight. It's surprising that they can take a much larger animal, but this stoat, ermine, or short tailed weasel ( all names for the same animal, you can see the black tip on his tail) is quite the fearless predator.

Anyone building a chicken coop- make it very tight, and if a rat can get in, so can a weasel.

Tuesday, January 31, 2017

cross cut sawyering

Our primary winter heating is with firewood, in our Russian furnace. ( masonry stove).

I cut and split my own firewood, using a chain saw for felling and bucking, and a maul for splitting.

I have been doing a bit of cross cut saw bucking ( cutting logs to firewood lengths), but am starting to get more serious about it. It's just one more step toward using less fossil fuels, and getting "functional exercise". I bought a new crosscut saw on line, and it works ok, but recently got an old one to add to my kit.

Turns out that sharpening a crosscut saw is more technical than I had realized. The definitive instructions are at this location, and what I have used for reference.

https://www.fs.fed.us/t-d/pubs/pdfpubs/pdf77712508/pdf77712508dpi72.pdf

I am taking a couple short cuts to their complete sharpening system, ( sharpening a saw correctly is time consuming!) but after I get better at filing, I may spring for the jointer tool, and try swaging the raker teeth that need it.

To be clear, I am no expert yet, and have a ways to go, but am sharing what I've learned so far.

Here is my homemade saw vise. I copied the design from a friend who crosscut saws and is good at improvising quick and functional tools. This is an old crosscut saw I was able to acquire that was still in pretty good shape. It had a few teeth that had not been sharpened correctly, but mostly I was just resharpening teeth that had dulled.


One end of the vise. You can see the wing nut and support stand. The vise can be tilted to out of vertical to one side or the other if desired for better angle for filing. This saw has Tuttle, or Champion tooth pattern, better for cutting hardwoods.




From left to right:
a spider, used to check the cutting teeth offset.

 A feeler gauge, used to adjust the spider, and to check the projection of the cutting teeth past the raker teeth.

A triangular file, for dressing the underside of the raker teeth.

A flat file, for sharpening the raker teeth tops and the cutting teeth.

A peening hammer, for adjusting the cutting teeth offset
a straight edge, for spanning between the cutting teeth to check the projection past the raker teeth, used with the feeler gauge.

A mini anvil, used with the hammer to make the offset bend in the cutting teeth.



I am not ready to fell trees with a crosscut yet, but might work toward that if I practice two man sawing with a friend. I also acquired a felling saw, but it needs a lot of work, so it will be a while before it's ready to cut.

I guess it's obvious, but buck the wood while it's still green! I have some dead elm and a few seasoned logs that didn't get bucked when green, so I will use my chainsaw on them.

One more thing I learned, is that a "normal" saw buck stand as found on the internet is too low for crosscut sawing. To prevent hunching over while sawing, the log needs to be up higher off the ground than you might get away with using a chainsaw. This also makes the base wider, which helps resist the side thrust that crosscut sawing causes, unlike chainsawing. I had made a sawbuck a few years ago for use with my chainsaw, but just added leg extensions to it, to much better effect on my back. This is the design I built, but have since raised it a good two feet( .6m).

http://www.arboristsite.com/community/threads/how-to-build-a-folding-sawbuck.247300/
